C3-100 IP-based Door Access Control Panel Door Controller

C3-100 IP-based Door Controller Panel

Access Control IP-based Door Controller Panel

C3-100 IP-based Door Controller Panel Description:

Our Access systems are built on flexible, open technology to provide easy management, real-time monitoring, and control of your access control system- all from a web browser. Simply download one instance of our free Windows-based v5.3 software (on a customer’s computer or Access InBridge appliance) and then manage the software from any computer’s web-browser which has administrative rights.

C3-100’s versatile design features take care of present and future needs with ease and efficiency. It is one of the most rugged and reliable door controllers on the market, with a multitude of built-in features.

C3-100 IP-based Door Controller Panel FEATURES:

• Over-current protection, over-voltage protection, and reversal protection for the power supply and all of the input and output terminals
• Reliable network system of controllers using either TCP/IP or RS-485 Serial communication
• Supports different Wiegand formats, and connects to readers as well as HID, Mifare, and generic ID card readers
• Connects with a variety of electric locks, sensors, exit buttons, alarm devices, and indicators
• Can be integrated with other security systems such as CCTV, Intrusion Detection, Fire Alarm Release, and Elevator Control for total security system. Directly compatible with biometric and fingerprint reader controllers.
• Easy-to-use and intuitive programming with Access Software
• System management by browser from client PC’s. No need to install software on each client
• Programming of special logic between doors is set up with simple pull down menus. No special scripts or code is required.
• Management software allows indication of real-time door status and remote commanding of door open/close states. Alarm conditions such as forced open and extended open alarms are reported.
• Advanced Access Control capabilities are built into the hardware, including Anti-Passback, Dual and Multi-Card Authentication, and Duress Mode.

ENQUIRE: C3-100 IP-based Door Controller Panel

First Name

Last Name

Email Address*

Telephone*

Quantity

COMMENT

Tags:

C3-100 Door Controller, Access Control, IP-based Door Controller, IP-based Door Panel

C3-200 IP-based Door Access Control Panel Door Controller

C3-200 IP-based Door Controller Panel

Access Control C3-200 IP-based Door Controller Panel

C3-200 IP-based Door Controller Panel Description:

Our Access systems are built on flexible, open technology to provide management, real-time monitoring, and control of your access control system- all from a web browser. Simply download one instance of our free Windows-based v5.3 software (on a customer’s computer or Access InBridge appliance) and then manage the software from any computer’s web-browser which has administrative rights.

C3-200’s versatile design features take care of present and future needs with ease and efficiency. It is one of the most rugged and reliable door controllers on the market, with a multitude of built-in features.

C3-200 IP-based Door Controller Panel FEATURES:

• RFID Cards: 30,000
• Transactions: 100,000
• Communication: RS485, TCP/IP
• Relay Outputs: 4 (2 x relays for locks) & (2 x Relays for AUX)
• Wiegand Inputs: 2 (26-bit & 34-bit)
• AUX Relay Inputs: 2
• Interfaces: 3rd Party locks, Door sensor, Exit button
• Functions: Anti-Passback, Duress, Interlock
• Data Backup: SD Card
• Power Supply: 12V DC 3A
• Dimensions: 106 x 218 x 15mm

ENQUIRE: C3-200 IP-based Door Controller Panel

First Name

Last Name

Email Address*

Telephone*

Quantity

COMMENT

Tags:

C3-200 IP-based , IP-based Door Controller, Door Controller Panel, Access control

C3-400 IP-based Door Access Control Panel Door Controller

C3-400 IP-based Door Controller Panel

Access Control C3-400 IP-based Door Controller Panel

C3-400 IP-based Door Controller Panel Description:

Our Access systems are built on flexible, open technology to provide management, real-time monitoring, and control of your access control system- all from a web browser. Simply download one instance of our free Windows-based v5.3 software (on a customer's computer or Access InBridge appliance) and then manage the software from any computer's web-browser which has administrative rights. C3-400's versatile design features take care of present and future needs with ease and efficiency. It is one of the most rugged and reliable door controllers on the market, with a multitude of built-in features.

C3-400 IP-based Door Controller Panel FEATURES:

• Over-current protection, over-voltage protection, and reversal protection for the power supply and all of the input and output terminals
• Reliable network system of controllers using either TCP/IP or RS-485 Serial communication
• Supports different Wiegand formats, and connects to our readers as well as HID, Mifare, and generic ID card readers
• Connects with a variety of electric locks, sensors, exit buttons, alarm devices, and indicators.
• Can be integrated with other security systems such as CCTV, Intrusion Detection, Fire Alarm Release, and Elevastor Control for total security system. Directly compatible with biometric and fingerprint reader controllers.
• Easy-to-use and intuitive programming with Access Software
• System management by browser from client PC’s. No need to install software on each client
• Programming of special logic between doors is set up with simple pull down menus. No special script or code is required.
• Management software allows indication of real-time door status and remote commanding of door open/close states. Alarm conditions such as forced open and extended open alarms are reported
• Advanced Access Control capabilities are built into the hardware, including Anti-Passback, Dual and Multi-Card Authentication, and Duress Mode.

ENQUIRE: C3-400 IP-based Door Controller Panel

First Name

Last Name

Email Address*

Telephone*

Quantity

COMMENT

Tags:

C3-400 IP-based , IP-based Door Controller, Door Controller Panel, Access control

inBio160 IP-based Biometric Door Access Control Panel Door controller

Access Control inBio160 IP-based Biometric Door controller Panel

Access Control IP-based Biometric Door controller Panel

inBio160 IP-based Biometric Door controller Panel Description:

InBio carries out the matching and verification of fingerprints on the panel, itself. The FR Series of fingerprint readers transmit fingerprint templates to InBio via RS-485 for fast and accurate matching with templates stored in a data-base. InBio controllers install easily on your network and support both TCP/IP and RS-485 communication. The auto-discovery tool allows settings and modifications of network parameters directly and easily.

InBio continues to operate even if the network connection is interrupted. Along with relay contacts for controlling door locks, easily programmable auxiliary relays can be used for additional control and interface to the lights, alarms, annunciators, intrusion detection panels, or even extra locking devices or gate controllers.

inBio160 IP-based Biometric Door controller Panel FEATURES:

• Over-current protection, over-voltage protection, and reversal protection for the power supply and all of the input and output terminals
• Reliable network system of controllers using either TCP/IP or RS-485 Serial communication
• Supports different Wiegand formats, and connects to fingerprint readers as well as HID, Mifare, and generic ID card readers
• Connects with a variety of electric locks, sensors, exit buttons, alarm devices, and indicators.
• Can be integrated with other security systems such as CCTV, Intrusion Detection, Fire Alarm Release, and Elevator Control for total security system. Directly compatible with biometric and fingerprint reader controllers.
• Easy-to-use and intuitive programming with the software
• System management by browser from client PC’s. No need to install software on each client
• Programming of special logic between doors is set up with simple pull down menus. No special scripts or code is required.
• Management software allows indication of real-time door status and remote commanding of doors' open/close states. Alarm conditions such as forced open and extended open alarms are reported
• Advanced access control capabilities are built into the hardware, including Anti-Passback, Dual and Multi-Card Authentication, and Duress Mode.

ENQUIRE: inBio160 IP-based Biometric Door controller Panel

First Name

Last Name

Email Address*

Telephone*

Quantity

COMMENT

Tags:

inBio160 IP-based Biometric , IP-based Biometric Door controller, Door controller Panel, Access control

inBio260 IP-based Biometric Door Access Control Panel Door controller

Access Control inBio260 IP-based Biometric Door controller Panel

Access Control IP-based Biometric Door Controller Panel

inBio260 IP-based Biometric Door controller Panel Description:

InBIO260 is a new concept access controller based on biometric fingerprint identification aims to improve the security of the users' life and information. This means that visitors need to place fingerprints on the fingerprint reader and the data collected is transferred to controller to verify.

InBIO260 is specially designed for applications like homes, offices and enterprises. Users may choose from Serial Communication or Ethernet to get linked to software (for central management), meanwhile, the distance between controller and RS485 readers could be more than 800m. InBIO260 is very convenient and safe for users to connect other security products using its groove socket. Its quietly brilliant working status is shown via the LED indicators on surface. Web-based management helps know about the local events on E-map and video remotely with real time control. We believe it is revolutionary to market in the world of access control.

inBio260 IP-based Biometric Door controller Panel FEATURES:

• SD Card data backup
• Onboard template storage
• Multiple hardware protection
• Dual communication mode
• Supports different Wiegand readers
• Input / Output ports to control doors
• Stores 30,00 fingerprint templates

ENQUIRE: inBio260 IP-based Biometric Door controller Panel

First Name

Last Name

Email Address*

Telephone*

Quantity

COMMENT

Tags:

inBio260 door controller Panel, IP-based Biometric Door controller, IP-based Biometric Door, Door Controller Panel, Access control

inBio460 IP-based Biometric Door Access Control Panel Door controller

Access Control inBio460 IP-based Biometric Door controller Panel

Access Control IP-based Biometric Door controller Panel

inBio460 IP-based Biometric Door controller Panel Description:

InBio carries out the matching and verification of fingerprints on the panels. The FR Series of fingerprint readers transmit fingerprint templates to InBio via RS-485 for fast and accurate matching with templates stored in database. Wiegand inputs are also provided for traditional RFID readers.

inBio460 IP-based Biometric Door controller Panel FEATURES:

• Advanced Access Control Built-In
• Truly Internal Biometric Identification
• Capacity
• Communication
• More than Door Control
• For Software Developers
• Lowest Total Cost of Ownership

ENQUIRE: inBio460 IP-based Biometric Door controller Panel

First Name

Last Name

Email Address*

Telephone*

Quantity

COMMENT

Tags:

inBio460 IP-based, IP-based Door Controller, Biometric Door controller Panel, Door Controller Panel, Access control
